Local Leak Testing Reduction Studies

These studies are reviews to optimize a site’s local leakage rate testing program. The resources required for Type B and C testing can be minimized while at the same time retaining a safe and effective program in full compliance with all applicable regulations.

Local Leak Testing Reduction Studies

This can be achieved by:

  • Reducing the number of Type B or C tests.
    Taking credit for water filled systems, water sealed systems and closed loops can greatly reduce the number of type B and C tests required to be performed.


  • Reduction in the number of As-Found tests required.
    Getting maximum advantage out of increased test intervals requires the proper definition of repairs and adjustments as well as maintenance/testing schedule coordination.


  • Optimization of administrative limits and total allowable leakage rate.
    The values chosen for administrative limits as well as the methodology for the conversion between units of %/day to slpm or scfh may both be optimized.


  • Use of equivalent flow rate conversions between water and air.
    The use of conversions from air to water is currently allowed and can reduce some high-pressure water testing. The conversions from water to air is allowed in the new revision of ANS 56.8 and allows for on-line quantification of Appendix J leakage rates where no Type C testing is possible.

  • Increasing the intervals between Type B and C tests.
    Option B to Appendix J as well as the most recent revisions to NEI 94-01 allow for significant extensions in Type B and C test intervals.


  • Minimizing time and labor needed for individual tests.
    Reductions may be achieved by examining testing methodology such as the venting and draining practices and valve line-ups.


  • Increased on-line testing.
    Moving some carefully chosen Type B and C tests from the outage to on-line testing can reduce outage workload and time.



Call Fluxion for a consultation for your site.
